Old 11-22-2008, 03:51 PM   #11 (permalink)
The Water Cooling Guru

aspire's Avatar

Join Date: Feb 2005
Location: United States
Posts: 5,308
Default Re: Water cooling just installed!

Looks good man.

I like how I can see my name on your buddy list in the screen cap.

Pink coolant ftw!

Need some pics of the whole thing together and running.

And no thanks for helping you? Pshhh.

Next time...

__________________

__________________
If I help you with something, you think I'm the bomb, or you just like what I said, rep me by clicking the star under my post.

Thanks!

The Official Tech Forums Water Cooling Informational Guide
aspire is offline
Old 11-22-2008, 05:57 PM   #12 (permalink)
Ultra Techie

Join Date: Oct 2003
Posts: 754
Send a message via AIM to slvrstang
Default Re: Water cooling just installed!

Quote:
Originally Posted by aspire.comptech View Post
Looks good man.

I like how I can see my name on your buddy list in the screen cap.

Pink coolant ftw!

Need some pics of the whole thing together and running.

And no thanks for helping you? Pshhh.

Next time...

Haha, thanks for all the help. I pretty much got everything exactly how you told me to. (except for the D5 instead of the 3.2
__________________

__________________

Q6600 G0 @ 3.80ghz
MCR-320-->Dtek Fuzion V2-->Dtek Fuzion GFX2-->Swiftech MCP-655-->
Asus P5K deluxe
4x1gb Crucial Ballistix @ 846mhz 5-5-5-15
8800GT
3x 250gb HDDs
Hiper 580w
Coolermaster 690 w/ water cooling mods
3dmark06 - 15,602
SuperPi 1M - 12.421s
slvrstang is offline
Old 11-23-2008, 12:58 AM   #13 (permalink)
Electical Engineer

BongWizard's Avatar

Join Date: Oct 2008
Location: OZ
Posts: 916
Send a message via AIM to BongWizard Send a message via Yahoo to BongWizard
Default Re: Water cooling just installed!

hey aspire... im thinking of building a new loop some time and im pretty set on these components, but have a look and tell me if there's anything you'd change

Danger Den D5 12V pump, Swiftech MCR-320 rad, D-Tek FuZion V2, XSPC Razor 4850 (will add a second when i've got the cash), 3 Yate Loon D12SH-12 fans, D-Tek Liquid F/X Alien Green UV Dye, Swiftech MicroRes Hi-Flo res, D-Tek 1/2" Nylon Barbs, D-Tek 1/2" Nylon Y-Splitters, ClearFlex 1/2" tubing, some standard hardware store #5 hose clamps and, of course, Arctic Silver 5 on the blocks... plus i might add in a custom temp sensor and flow meter

let me know what you think... im trying to avoid the tline thing, because i know i'll end up draining it quite a bit, and i know that a res fills wicked faster than through a t
__________________

NZXT Lexa BlackLine w/ Red LEDs | Corsair TX-750 | Gigabyte EP45-DS3P | Intel Core 2 Quad Q9300 @ 3.6GHz
2x 2GB Kingston HyperX PC2-6400 @ 960MHz (5-4-4-13) | 3x Seagate Barracuda 7200.11 500GB HDD in RAID5
2x HIS Radeon HD 4850 @ 761/1129 in CrossFireX w/ Thermaltake DuOrbs | Creative X-Fi XtremeGamer Fatal1ty Pro



Got a problem?? Click Here before posting!

BongWizard is offline
Old 11-23-2008, 01:08 AM   #14 (permalink)
Ultra Techie

Join Date: Oct 2003
Posts: 754
Send a message via AIM to slvrstang
Default Re: Water cooling just installed!

Quote:
Originally Posted by BongWizard View Post
hey aspire... im thinking of building a new loop some time and im pretty set on these components, but have a look and tell me if there's anything you'd change

Danger Den D5 12V pump, Swiftech MCR-320 rad, D-Tek FuZion V2, XSPC Razor 4850 (will add a second when i've got the cash), 3 Yate Loon D12SH-12 fans, D-Tek Liquid F/X Alien Green UV Dye, Swiftech MicroRes Hi-Flo res, D-Tek 1/2" Nylon Barbs, D-Tek 1/2" Nylon Y-Splitters, ClearFlex 1/2" tubing, some standard hardware store #5 hose clamps and, of course, Arctic Silver 5 on the blocks... plus i might add in a custom temp sensor and flow meter

let me know what you think... im trying to avoid the tline thing, because i know i'll end up draining it quite a bit, and i know that a res fills wicked faster than through a t
That all looks good to me, but I'd suggest a fan controller for the D12SH-12s. They're pretty loud at max speed, they're nice and quiet at about 80% though.
__________________

Q6600 G0 @ 3.80ghz
MCR-320-->Dtek Fuzion V2-->Dtek Fuzion GFX2-->Swiftech MCP-655-->
Asus P5K deluxe
4x1gb Crucial Ballistix @ 846mhz 5-5-5-15
8800GT
3x 250gb HDDs
Hiper 580w
Coolermaster 690 w/ water cooling mods
3dmark06 - 15,602
SuperPi 1M - 12.421s
slvrstang is offline
Old 11-23-2008, 01:47 AM   #15 (permalink)
The Water Cooling Guru

aspire's Avatar

Join Date: Feb 2005
Location: United States
Posts: 5,308
Default Re: Water cooling just installed!

Quote:
Originally Posted by BongWizard View Post
hey aspire... im thinking of building a new loop some time and im pretty set on these components, but have a look and tell me if there's anything you'd change

Danger Den D5 12V pump, Swiftech MCR-320 rad, D-Tek FuZion V2, XSPC Razor 4850 (will add a second when i've got the cash), 3 Yate Loon D12SH-12 fans, D-Tek Liquid F/X Alien Green UV Dye, Swiftech MicroRes Hi-Flo res, D-Tek 1/2" Nylon Barbs, D-Tek 1/2" Nylon Y-Splitters, ClearFlex 1/2" tubing, some standard hardware store #5 hose clamps and, of course, Arctic Silver 5 on the blocks... plus i might add in a custom temp sensor and flow meter

let me know what you think... im trying to avoid the tline thing, because i know i'll end up draining it quite a bit, and i know that a res fills wicked faster than through a t
For an MCR style rad High speed fans wont give you any gains as the rad is optimized for low speed performance.

MX-2 outperforms AS5

Dye's and coolants are terrible, nothing outperforms pure distilled water with some biocide added.

Flow meter is useless and will only restrict flow.

Why would you use nylon barbs? Go for Bitspower/Danger Den Fatboys.
__________________
If I help you with something, you think I'm the bomb, or you just like what I said, rep me by clicking the star under my post.

Thanks!

The Official Tech Forums Water Cooling Informational Guide
aspire is offline
Old 11-23-2008, 03:49 PM   #16 (permalink)
Ultra Techie

Join Date: Oct 2003
Posts: 754
Send a message via AIM to slvrstang
Default Re: Water cooling just installed!

Higher fan speed will help, it's just not a linear gain.

At an average heat load of 235w, the 3000rpm scythe gives almost a 4* difference on water temps over the slower D12SM yate @ 1000rpm. I still say go with the D12SH's and get a fan controller for when you don't really care about 4*.

__________________

Q6600 G0 @ 3.80ghz
MCR-320-->Dtek Fuzion V2-->Dtek Fuzion GFX2-->Swiftech MCP-655-->
Asus P5K deluxe
4x1gb Crucial Ballistix @ 846mhz 5-5-5-15
8800GT
3x 250gb HDDs
Hiper 580w
Coolermaster 690 w/ water cooling mods
3dmark06 - 15,602
SuperPi 1M - 12.421s
slvrstang is offline
Old 11-23-2008, 04:08 PM   #17 (permalink)
The Water Cooling Guru

aspire's Avatar

Join Date: Feb 2005
Location: United States
Posts: 5,308
Default Re: Water cooling just installed!

I can guarantee the difference will not be 4C...

Martin did some great testing but I'm gonna have to say those are severely inflated numbers.

With such a low heat load, 235W is nothing for a triple rad, moving more air through isn't going to drop your temps as much as if you had a saturated rad.
__________________
If I help you with something, you think I'm the bomb, or you just like what I said, rep me by clicking the star under my post.

Thanks!

The Official Tech Forums Water Cooling Informational Guide
aspire is offline
Old 11-23-2008, 05:17 PM   #18 (permalink)
Electical Engineer

BongWizard's Avatar

Join Date: Oct 2008
Location: OZ
Posts: 916
Send a message via AIM to BongWizard Send a message via Yahoo to BongWizard
Default Re: Water cooling just installed!

i thought i read somewhere that swiftech mcrs where design for near silent performance... the only reason i wanna use the high speed yateloons is the fact that when i bought my case i swapped out the standard fans for yateloons, and i figure i can whack the stock fans back in the case and use the yates for WC... considering low speed yates are the same price as high speeds, i'll probably just grab a variable resistor and use it as a fan controller

i've heard MX-2 performs slightly better, but i haven't found a shop in Australia that sells it, but everywhere has AS5

the flow meter and temp sensor where really more of a dream... im not too keen to pay $30 for each of them, and i was thinking i could build something similar for $10... but im just too lazy these days, so that was out as soon as i thought about it

would adding a few mL of uV reactive dye make that much of a difference in the thermal conductivity of the overall fluid? i didnt think it would make a noticable difference... if it does, what kind of biocide would you recommend?

also, i chose nylon barbs because that avoids the possibilty of galvanic corrosion of the connectors and blocks (cuz i think those ones you mentioned are chrome, right?)... i know its a relatively slow process... but running this thing with a high flow rate 24/7 will certainly expedite it
__________________

NZXT Lexa BlackLine w/ Red LEDs | Corsair TX-750 | Gigabyte EP45-DS3P | Intel Core 2 Quad Q9300 @ 3.6GHz
2x 2GB Kingston HyperX PC2-6400 @ 960MHz (5-4-4-13) | 3x Seagate Barracuda 7200.11 500GB HDD in RAID5
2x HIS Radeon HD 4850 @ 761/1129 in CrossFireX w/ Thermaltake DuOrbs | Creative X-Fi XtremeGamer Fatal1ty Pro



Got a problem?? Click Here before posting!

BongWizard is offline
Old 11-23-2008, 06:07 PM   #19 (permalink)
The Water Cooling Guru

aspire's Avatar

Join Date: Feb 2005
Location: United States
Posts: 5,308
Default Re: Water cooling just installed!

Quote:
Originally Posted by BongWizard View Post
would adding a few mL of uV reactive dye make that much of a difference in the thermal conductivity of the overall fluid? i didnt think it would make a noticable difference... if it does, what kind of biocide would you recommend?

also, i chose nylon barbs because that avoids the possibilty of galvanic corrosion of the connectors and blocks (cuz i think those ones you mentioned are chrome, right?)... i know its a relatively slow process... but running this thing with a high flow rate 24/7 will certainly expedite it
UV reactive dye will coagulate and gunk up your blocks. Avoid it.

If you want to have glowing W/C use Feser UV Tubing.

For biocide any aquarium grade stuff will do.. Petras sells some good stuff for like 2.50...

Barbs are all Nickel Plated Brass and will not lead to galvanic corrosion. Trust me on this, metal barbs will not cause corrosion.
__________________
If I help you with something, you think I'm the bomb, or you just like what I said, rep me by clicking the star under my post.

Thanks!

The Official Tech Forums Water Cooling Informational Guide
aspire is offline
Old 11-23-2008, 06:59 PM   #20 (permalink)
Camera junky

Poizen22's Avatar

Join Date: Jul 2006
Location: ottawa ontario canada.
Posts: 6,280
Default Re: Water cooling just installed!

um wow with those temps push for 4.0
__________________

__________________

https://www.flickr.com/photos/poizen22/
intel Core I7 8700k@ 5.0ghz-Nvidia GTX1080 ti ftw3-Aorus 5 z370 mobo-16gb ddr4 G-Skill trident Z rgb 3000mhz - 1tb samsung 960 pro, 2tb wd blue- thermaltake rgb 750w gold-Phanteks pro M TG- Samsung CHG70 1440p 144hz 32 inch QLED.
Poizen22 is offline
